L Timing Pulley

Parameter for L timing pulley:

L (pitch 9.525) - light

Apply for Vending machines, wipers, packaging machines, elevators, ice breakers, industrial dryers, unmanned golf carts.

Computer, copier, plastic mirror grinder, food machinery, seaweed taking machine.

Mechanism of "tooth climbing" phenomenon in the use of toothed synchronous belt.

Although synchronous belt drive has many advantages, it also has many defects, such as short service life, no wear resistance, serious tooth peeling, meshing, tooth skipping, vibration and so on.

With the transmission error generated in the transmission process and transmission movement of the synchronous belt, the synchronous belt will be placed on the tooth profile surface of the tooth groove. Due to the error accumulation of N times, the belt teeth will climb to the top circle of the pulley and the synchronous tooth belt will slip on the top circle of the pulley. This is the so-called "tooth climbing" phenomenon.

Type:  L Timing belt

texture of material: Rubber, polyurethane, PU, nylon canvas, neoprene, glass fiber thread.

Tooth profile: Single side tooth.

Scope of application: Textile, machine tool, tobacco, communication cable, light industry, chemical industry, metallurgy, instrumentation, food, mining, petroleum, automobile.

Applicable environment: Aging resistance, heat resistance, oil resistance and abrasion resistance.

L timing pulley customization instructions

Users customize l synchronous pulley. Please provide the drawing of L synchronous pulley (in the drawing, it is not necessary to draw the tooth size of the pulley). The company can also draw the drawing of L synchronous pulley for users according to the specifications, inner hole, keyway width and other dimensions provided by users; It can also provide users with surveying and mapping l synchronous pulley and other services.

L the outer diameter tolerance, end face runout and radial runout of the synchronous pulley shall comply with the provisions of the pulley design table.

L the width of the tooth surface of the timing belt selected for the timing belt of the timing belt pulley must meet the requirements specified in the pulley design table.
