Pu Timing Belt
China Pulley suppliers

PU Timing Belt

Name: China Customized PU Timing Belt Suppliers, Manufacturers - Factory Direct Wholesale - SSTMACHINERY
Brand: SSTMACHINERY
SKU: 157026928

SSTmachinery make good quality PU timing belt. PU (polyurethane) or other material. Inside steel cord. ISO, ANSI, DIN standard.

Send Inquiry

Product Introduction

PU timing belt:

SST machinery polyurethane timing belts are used for high load and resistance applications.

The high qualitypolyurethane gives excellent abrasion and shear resistance, combined with a variety of graded steel cords, ensuring high strength and tractive resistance. The result is a timing belt with excellent dimensional stability.

Our range of high quality polyurethane timing belts are manufactured to a tight tolerance range, which assures consistent length and thickness. The combination of these factors results in these belts performing to the highest physical and chemical levels.

PU timing belts are suitable for high power and precision motion control, even at high speeds.

These timing belts come in a wide range of pitches and also in form of open rolls which can be used for a wide variety of applications in various different industries.

The structure of polyurethane synchronous belt is composed of belt back, tensile layer and belt teeth.

PU timing belt

The back of the polyurethane synchronous belt is used to bond and wrap the tensile elements. It should have good flexibility and flex fatigue resistance, not easy to aging, good oil resistance and wear resistance. The inner surface of the polyurethane synchronous belt back is provided with a sharp angle groove of appropriate size, which can not only improve the flex fatigue performance of the toothed belt due to the process requirements, but also make the intercepted air between the belt and the gear teeth escape during operation, so as to eliminate part of the noise.

The white PU timing belt is a food grade conveyor belt. The processing of the green conveyor belt is slightly different from that of the white conveyor belt. The surface is soft, and the hardness is relatively large. It can be made into an oil resistant and grease resistant conveyor belt. The white polyurethane (PU) conveyor belt not only has the characteristics of high tensile strength, good flexibility, light, thin, and tough, but also is oil resistant, non-toxic, hygienic, and easy to clean. This kind of conveyor belt conforms to the sanitary standard, is wear-resistant, anti physical aging, and is a durable conveyor product.
