push and pull fast coupling

Adopted high grade of carbon steel, SST machinery produces push and pull fast coupling, this kind of coupling consists of two parts, we shut it off with a poppet valve, the male part of coupling can be connected under pressure, while it is not allowed to be disconnect under pressure, which follows the emergency break away function of standard ISO5675, this coupling can interchange with ISO 7241-1 A series.

Hydraulic push and pull fast coupling has a joint that can realize the quick connection or disconnection of pipeline without tools. It has four main structural forms: straight-through type, single-closed type, double-closed type, and safe and leak-free type. The materials are mainly carbon steel, stainless steel and brass, we can proceed the production according to our customers' requirements.

Our standard export packaging for push and pull fast coupling is individual packaging, that is we will put our couplings into one small individual box, and then bigger marster boxes, the last we will use plywood pallet to protect our couplings from long-time sea delivery, we also accept cusotm packaging, like indicated barcodes or lables on outside of individual boxes or marster boxes, the dimension of all boxes will also be customized according to your demand. please contact our sales team for further discussion.

With over 10 years of experience in transmission design and manufacturing, SST machinery enjoys a good reputation among its customers and exported its goods to EU, USA, south American, ASIA etc.
